Cytospin 4

Description

• Processes 12 specimens at one time
• Accepts all protocols from Cytospin 1, 2 and 3
• Allows for one-handed opening and closing with a redesigned lid-release mechanism
• Enables viewing of the sealed head through the polycarbonate window during operation
• Protects mechanical and electronic components from damage due to accidental fluid spills
• Designed for easy disinfection
• Meets stringent IEC 61010 safety standards

Protects Users and Specimens

• Allows loading of the sealed head inside a microbiological cabinet for ultimate safety
• Features an auto-locking, plastic outer lid
• Operates only when lid is locked and keeps lid locked during rotation
• Includes disposable sample chambers with caps and a wipe-clean control panel
• Sounds an audible alarm when the cytocentrifuge is out of balance, outside the speed tolerance or if the lid is not properly locked
• Uses specimen safety alarms at one-minute intervals to remind users to remove specimens to prevent air drying and ensure consistent results

Provides Excellent Presentation

• The cytocentrifuge deposits cells onto a clearly defined area of a glass slide and allows for the absorption of the residual fluid into the sample chamber's filter card
• Cytocentrifugation constructively flattens cells for excellent nuclear presentation
• During operation, the instrument's spinning action tilts the Shandon™ Cytofunnels™ upright and centrifuges cells onto the deposition area of the slide, giving all cell types equal opportunity for presentation
• In the Load or Stop position, the tilting feature reduces cell loss by preventing residual fluid from coming into contact with the prepared slide

Offers Simple and Precise Controls

• Pull-out program card logs up to nine programs for fast, convenient retrieval
• Protected program memory stores up to 23 routines for instant recall and protects from power loss
• Easy-touch program keypad allows for easier keystrokes and more intuitive programming
• Speed window displays programmed spinning speeds from 200 to 2000 rpm
• Three acceleration-control buttons allow the operator the flexibility to protect fragile samples
• Time window displays the programmed and remaining run time from 1 to 99
• Control feature has a standby power-saving mode; displays are also turned on and off by the standby key

Physical Specifications

• Dimensions (W × D × H): With closed lid: 16 × 9.5 × 24.5 in. (40.5 × 24 × 62 cm)
• With open lid: 16 × 25 × 24.5 in. (40.5 × 62.5 × 62 cm)
• Weight: 26.5 lb. (12 kg)
• Power Requirements: 100–240 VAC, 50/60 Hz, 1Ph, 150 VA Max.
